Amtrol 20 Gall Vertical Boiler Expansion Tank 1" NPT 11.3 Gallons Max

Model: SX-40V Item Number: 45588
Amtrol SX-40V
PREVIOUS
NEXT
Amtrol SX-40V
Amtrol SX-40V
Amtrol SX-40V
Enlarge Image
Amtrol SX-40V
Amtrol SX-40V
Amtrol SX-40V
View All
Our Price: $303.00
synchrony card icon
$51 / Month
Suggested monthly payments with 6 month financing.
In-Stock
Ships Thursday, November 14th
Shipping to60601
Amtrol 20 Gall Vertical Boiler Expansion Tank 1
Amtrol 20 Gall Vertical Boiler Expansion Tank 1" NPT 11.3 Gallons Max Model: SX-40V Item Number: 45588
$303.00
In-Stock
-
+
Features
Specifications
Reviews
Product Q&A
Manuals
Shipping Crate Icon
Free Shipping Learn More
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges map apply, see our full shipping policy for more details.
Specification Highlights
    Condition
    New Learn More
    New
    This product is new and has never been used. It's in its original packaging, which has not been opened.
    Product Category
    Boiler Accessories
    UPC
    642031119896
Storage Volume (Gallons)
Select Attribute
Features
View More

Features

Overview for Amtrol SX-40V

In 1954, Amtrol invented the first expansion tank to control pressure build-up and energy consumption in heating and chilled water systems. More than 50 years later the SX is still the one of the world?s leading floor-standing expansion tanks and is proudly made in the USA! The SX vertical boiler system expansion tank collects the expanded water as system temperatures rise which reduces potentially dangerous pressure build-up. Equipped with a 100 percent tested sealed air cushion, water-tight reservoir, air stem for pre-charge adjustment, and a deep drawn steel tank, the SX is reliable and built to last. The SX-40V is ideal for large residential and light commercial applications and can be used with high output boilers.
  • USA Made
  • All SX thermal expansion tanks are made in the USA.
  • Heavy Duty Tank
  • From the deep drawn steel tank to the water-tight reservoir for expanded water, this thermal expansion tank is constructed for maximum strength and efficient energy consumption.
  • Eliminates Wasted Energy
  • Expanded water caused by thermal expansion is collected by the SX tank which returns the water back to your system which preventing faucet drips, intermittent toilet fill, and pressure relief valve discharge.
  • Protection for Your System
  • SX thermal expansion tanks are designed to protect your water heater, fixtures, and appliances by preventing dangerous pressure build up.
  • Specifications
    View More

    Specifications

    Overview
    Product Category
    Boiler Accessories
    UPC
    642031119896
    General Information
    Product Line
    Extrol
    Product Category
    Boiler Accessories
    Connection Type
    NPT
    Performance
    Maximum Operating Temperature
    240 F
    Maximum Operating Pressure
    100 PSI
    Dimensions
    Storage Volume
    20 Gallons
    Maximum Acceptance Volume
    11.3 Gallons
    Connection Size
    1 Inch
    Product Diameter
    15 Inches
    Product Height
    33 Inches
    Shipping Width
    15 Inches
    Shipping Height
    32 Inches
    Shipping Length
    15 Inches
    Certifications
    Country of Origin
    United States
    Warranty Information
    Warranty Learn More
    Warranty
    A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab.
    1 Year
