Aspen Mini Lime - Mini Split Condensate Pump Kit - Universal Voltage - Up to 54,000 BTU/hr

Model: ASP-ML-UNI Item Number: 31129
Aspen ASP-ML-UNI
PREVIOUS
NEXT
Aspen ASP-ML-UNI
Enlarge Image
Our Price: $364.55
synchrony card icon
$61 / Month
Suggested monthly payments with 6 month financing.
Only 2 In-Stock
Ships Thursday, December 19th
Shipping to60601
Aspen Mini Lime - Mini Split Condensate Pump Kit - Universal Voltage - Up to 54,000 BTU/hr
Aspen Mini Lime - Mini Split Condensate Pump Kit - Universal Voltage - Up to 54,000 BTU/hr Model: ASP-ML-UNI Item Number: 31129
$364.55
Only 2 In-Stock
-
+
Accessories
Features
Specifications
Reviews
Product Q&A
Manuals
Shipping Crate Icon
Free Shipping Learn More
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges map apply, see our full shipping policy for more details.
Specification Highlights
    Condition
    New Learn More
    New
    This product is new and has never been used. It's in its original packaging, which has not been opened.
    Weight
    0.68 Pounds Learn More
    0.68 Pounds
    Total weight of the product and any included accessory/components. This total is not the shipping weight, as it does not include packing material, which may increase the overall shipping weight of this product.
    Type
    Condensate Pump
    Product Line
    Mini Lime
Recommended Accessories
View More
Required Accessories Add All Required
Installation Accessories
Features
View More

Features

Overview for Aspen ASP-ML-UNI

A properly functioning mini split system requires an installation that allows for proper condensate drainage. Condensate removal pumps are used in situations where gravity draining is not an option and more power is needed. If you're using high wall split systems, you may need an alternative way to expel water that has been removed by the cooling system. Aspen's ASP-ML-UNI Mini Lime Condensate Pump is a compact and discrete pump, designed for great performance easy install and maintenance. Aspen's ASP-ML-UNI is perfect for commercial use in offices and restaurants and applications where easy access for future service is key.
  • Designed for Versatile Installation
  • Aspen Mini Split Condensate Pump Kits like the ASP-ML-UNI are designed to easily mount within a dedicated trunking system and focus on reliability with an anti-siphon device to keep air from seeping into your pump and causing priming issues.
  • Performance that Packs a Punch
  • The ASP-ML-UNI has a max flow rate of 3 GPM that'll keep your system running smoothly. Each unit also features an anti-siphon device that makes sure your pump is always primed, keeping air from leaking in and causing problems.
  • Universal Voltage
  • The Aspen ASP-ML-UNI Mini Lime is compatible with all voltages allowing for an easy integration into your existing components.
  • Variety of Trunking Options
  • Aspen Mini Lime Mini Split Condensate Pump Kit like the ASP-ML-UNI sit comfortably in a trunking elbow and are available with a wide range of trunking accessories for aesthetically-pleasing covers that provide a protected conduit for condensate lines.
  • Product Includes
  • (1) 300mm Discharge Tube 6mm ID
  • (1) 1.5m Hard Wired Power Cable
  • (1) 220 Lime Green Inlet Hose 14mm ID
  • (1) 150mm Vinyl breather tube 6mm ID
  • (1) Anti siphon device
  • (1) Elbow Front and Back
  • (1) 800mm Conduit Front and Back
  • (1) Internal Conduit Sleeve
  • (1) Gasket
  • (1) Ceiling Plate
  • (1) Drain connector kit
  • (1) Fixing kit
  • (1) Install manual
  • Product Note
    The Aspen ASP-ML-UNI is suitable for use with large commercial high wall mini split systems. The ASP-ML-UNI is designed to sit in a trunking elbow to the left or right of your evaporator unit and is ideal for applications where easy access for future maintenance is key.
    Specifications
    View More

    Specifications

    General Information
    Type
    Condensate Pump
    Product Line
    Mini Lime
    Application
    In-Conduit
    Trim Color
    Ivory
    UPC
    021449838498
    Performance
    Maximum Input Capacity Learn More
    Maximum Input Capacity
    The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
    54000 BTU
    Maximum Head
    32.81 Feet
    Maximum Sound Level Learn More
    Maximum Sound Level
    Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
    23 dB
    Condensate Removal Rate
    3 GPH
    Electrical Data
    Current Draw
    0.1 Amps
    Dimensions
    Product Height
    4 1/2 Inches
    Product Width
    1 35/48 Inches
    Product Depth
    3 36/40 Inches
    Product Weight
    0.68 Pounds
    Certifications
    Country of Origin
    UK
    CSA Listed
    Yes
    Warranty Information
    Warranty Learn More
    Warranty
    A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab.
    1 Year
