Revolv 53,000 BTU Multi-Position Mobile Home Electric Furnace

Model: RE9X15N4 Item Number: 77170
Revolv RE9X15N4
PREVIOUS
NEXT
Revolv RE9X15N4
Revolv RE9X15N4
Revolv RE9X15N4
Enlarge Image
Revolv RE9X15N4
Revolv RE9X15N4
Revolv RE9X15N4
View All
Product Discontinued
Sorry, this product is no longer available.
Try This Instead
Specification Highlights
    Condition
    New Learn More
    New
    This product is new and has never been used. It's in its original packaging, which has not been opened.
    Weight
    94.5 Pounds Learn More
    94.5 Pounds
    Total weight of the product and any included accessory/components. This total is not the shipping weight, as it does not include packing material, which may increase the overall shipping weight of this product.
    Type
    Electric Furnace
    Product Line
    RE9
Recommended Accessories
View More
Required Accessories Add All Required
Installation Accessories
Features
View More

Features

Overview for Revolv RE9X15N4

Revolv is dedicated to bringing efficient comfort to the manufactured and mobile home market. The RE9X15N4 is a multi-directional electric furnace capable of providing 53,000 BTU of heating at 100% efficiency. Designed for easy installation in a variety of manufactured and modular homes, it enjoys a 0" required clearance to combustibles at the rear and sides and only 6" are required at the front of the unit. If you're struggling to effectively and safely heat your manufactured home, the RE9X15N4 is a solution that you can believe in.
  • Nichrome Heating Elements
  • Revolv electric furnaces feature nichrome heating elements, designed to provide long lasting, efficient heating without breaking the bank.
  • Multi-Positional Installation
  • The Revolv RE9X models are designed specifically to fit any installation. They can be used in both upflow and downflow systems making them the perfect fit for any home.
  • Multiple Cooling Choices
  • RE9X models can be paired with either air conditioners or heat pumps up to a maximum of 4 tons of cooling.
  • High Quality, Low Maintenance
  • Features such as sealed bearings on the motors, reliable controllers, and a built-in circuit breakers means these units are made to last and provide uninterrupted comfort for years.
  • Multi-Speed Fan
  • The RE9X15N4 uses a four-speed motor for the blower, giving you excellent airflow that can be scaled to the size of your home.
  • Product Note
    Grille not included.
    Specifications
    View More

    Specifications

    General Information
    Type
    Electric Furnace
    Product Line
    RE9
    Fuel Type Learn More
    Fuel Type
    To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
    Electric
    Modulating/Staging Learn More
    Modulating/Staging
    Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control.
    Single Stage
    Blower Motor Type
    PSC Multi-Speed
    Configuration Learn More
    Configuration
    Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
    Downflow/Upflow
    UPC
    663132344239
    Performance
    Heating BTU
    53000
    Electric Heat Capacity
    15 kW
    Electrical Data
    Phase
    1
    Frequency
    60 Hz
    Minimum Circuit Ampacity
    82 Amps
    Recommended Breaker Size
    82 Amps
    Dimensions
    Product Height
    29 Inches
    Product Width
    20 Inches
    Product Depth
    24 3/4 Inches
    Product Weight
    94.5 Pounds
    Shipping Weight
    94.5 Pounds
    Warranty Information
    Parts Warranty Show ACW Parts Warranty Learn More
    Parts Warranty
    A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
    2 Years
