Weil-McLain Aqua Logic Low Profile Indirect Water Heater 18.2 Gal.

Model: 633800513 Item Number: 50024
Weil-McLain 633800513
PREVIOUS
NEXT
Weil-McLain 633800513
Enlarge Image
Product Discontinued
Sorry, this product is no longer available.
Specification Highlights
    Condition
    New Learn More
    New
    This product is new and has never been used. It's in its original packaging, which has not been opened.
    Weight
    70 Pounds Learn More
    70 Pounds
    Total weight of the product and any included accessory/components. This total is not the shipping weight, as it does not include packing material, which may increase the overall shipping weight of this product.
    Type
    Indirect Water Heater
    Product Line
    WM97 Plus
Recommended Accessories
View More
Installation Accessories
Oatey 24" Aluminum Water Heater Pan w/ 1" PVC Fitting
Model: 34153
Qty
$23.00
In-Stock
Add To Cart
Burnham Sage Zone Control - Valve Panel
$284.00
Ships in 4-7 Business Days
Model: 104589-01
Qty
$284.00
Ships in 4-7 Business Days
Add To Cart
Holdrite Quick Strap Deluxe Powdercoated for Water Heater Up to 80 Gal
Model: QS-50-D
Qty
$31.00
In-Stock
Add To Cart
Holdrite Quick Strap Galvanized Water Heater Strap Up to 80 Gallons
Model: QS-50-P
Qty
$27.00
In-Stock
Add To Cart
Features
View More

Features

Overview for Weil-McLain 633800513

Adding high efficiency domestic hot water production to a Weil-McLain WM97+ hot water boiler could not be easier than with the Aqua Logic companion water heater. This indirect fired water heater was designed specifically to interface with the WM97+ line, and the wiring harness is preconfigured for a quick plug and play setup. Once set up, the WM97+'s control and display enable additional features for the Aqua Logic, unavailable on traditional indirect fired water heaters. Through the boiler control, users have access to a high production mode, for maximum hot water, and an economy mode, for maximum efficiency. This flexibility means that the Aqua Logic is suited for a variety of applications, including those with shifting hot water requirements. Regardless of application, a three speed Taco circulator and a Honeywell thermostatic mixing valve assure a safe and comfortable temperature of hot water for every fixture.
  • Low Profile
  • The Aqua Logic water heater is designed to slide directly underneath a wall-mounted WM97+ hot water boiler. Space heating and domestic hot water production can be condensed into an attractive column with dimensions of 73.5" H x 25.25" W x 19.3125" D.
  • Programmable Schedule
  • Using the WM97+'s control panel, the Aqua Logic may be set to adhere to a schedule. High demand times such as the early morning may be designated as such without sacrificing efficiency in the afternoon, when less hot water is needed.
  • Product Includes
  • (1) Weil-McLain Aqua Logic Companion Water Heater
  • (1) Honeywell AMX302TLF Thermostatic Mixing Valve
  • (1) Taco Three Speed Circulator
  • (1) 3/4" Temperature and Pressure Valve
  • (1) Drain Valve
  • (2) Flexible Stainless Steel Connection Hoses
  • (1) Preconfigured Wiring harness with Plugs
  • (2) Tank Temperature Sensors
  • (3) Adjustable Leveling legs
  • Product Compatible With
  • Weil-McLain WM97+ Hot Water Boilers
  • Specifications
    View More

    Specifications

    General Information
    Type
    Indirect Water Heater
    Product Line
    WM97 Plus
    Medium Learn More
    Medium
    Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
    Hot Water
    Fuel Type Learn More
    Fuel Type
    To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
    Indirect Fired
    Storage Type
    Tank
    Coils Quantity
    1
    Connection Type
    NPT
    Mount Type
    Floor
    UPC
    0672619198388
    Performance
    Minimum Input Capacity
    113000 BTU
    First Hour Delivery Learn More
    First Hour Delivery
    Sometimes called First Hour Rating, this is the number of gallons of hot water the heater can supply per hour when starting with a fully heated tank. The recovery of the water heater depends on your boiler's BTU and boiler output temperature.
    187 Gallons
    Continuous Recovery Rate
    172 Gallons
    Dimensions
    Storage Volume
    18.2 Gallons
    Cold Water Inlet
    3/4 Inch
    Hot Water Outlet
    3/4 Inch
    Supply Connection
    1 Inch
    Return Connection
    1 Inch
    Product Height
    40 3/16 Inches
    Product Width
    19 Inches
    Product Depth
    19 5/16 Inches
    Product Weight
    70 Pounds
    Shipping Weight
    80 Pounds
    Warranty Information
    Parts Warranty Show ACW Parts Warranty Learn More
    Parts Warranty
    A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
    2 Years
    Vessel Warranty
    10 Years
