Emerson Ignition Module/Circulator Control Kit & Nitride Ignitor
Emerson Ignition Module/Circulator Control Kit & Nitride Ignitor Model: 21M51U-843 Item Number: 35856
$268.00
In-Stock
-
+
Features
Specifications
Reviews
Product Q&A
Manuals
Shipping Crate Icon
Free Shipping Learn More
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges map apply, see our full shipping policy for more details.
Specification Highlights
    Condition
    New Learn More
    New
    This product is new and has never been used. It's in its original packaging, which has not been opened.
    Product Category
    Thermostats and Controls
    UPC
    662766460957
Features
View More

Features

Overview for White Rodgers 21M51U-843

The 50M51-843 is a universal replacement control for two-stage automatic gas ignition controls employing a microprocessor to continually monitor, analyze, and control the proper operation of the gas burner and inducer. The 50M51-843 controls a multiple tapped induction circulation blower. Signals interpreted during continual surveillance of the twostage thermostat and flame sensing element initiate automatic ignition of the burner, sensing of the flame, and system shutoff during normal operation. The control incorporates system fault analysis for quick gas flow shutoff, coupled with automatic ignition retry upon sensing a fault correction. The 50M51-843 quickly and easily replaces White-Rodgers 50M51-XXX controls. This kit includes: a 50M51-843 Ignition Control Module, a 21D64-2 Ignitor Kit.
  • White Rodgers 21M51U-843 Features
  • 120 VAC Ignitor Output
  • 120 VAC Two-Speed Inducer Output
  • 120 VAC Humidifier Output
  • 120 VAC Electronic Air Cleaner Output
  • 120 VAC 3-Speed PSC (Permanent Split Capacitor) Circulator Output
  • 2-Stage Gas Valve Output
  • Fuse Protection - 3 Amp
  • Furnace Status LED - Tri-Color (Green, Red and Amber)
  • Heat Fan OFF Delay (Dipswitch Selectable)
  • Fan ON Delay for Cooling
  • Auto Second Stage Delay (Dipswitch Selectable Mode)
  • Historical Fault Retrieval by Pushbutton
  • YLO, Y, W1, W2, R, G, C, TWIN Terminals
  • Pressure Switch Inputs and Monitoring
  • Flash Microprocessor with Non-Volatile Memory
  • Flame Current Measurement Points
  • Specifications
    View More

    Specifications

    Overview
    Product Category
    Thermostats and Controls
    UPC
    662766460957
    General Information
    Type
    Ignitor
    Product Category
    Thermostats and Controls
    Dimensions
    Shipping Weight
    5.1 Pounds
    Warranty Information
    Warranty Learn More
    Warranty
    A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab.
    1 Year
